Timpano Audio TPT-DH175 1" Exit Phenolic Diaphragm Driver + Plastic Horn

TPT-DH175 1? Exit Phenolic Diaphragm Driver + Plastic Horn

The Timpano TPT-DH175 is a 1? phenolic dome compression driver specially designed to offer a smooth extended frequency response over a broad band, from mids to highs, with very high efficiency. Ideal for compact two- and three way systems. The 4.5? x 4.5? horn produces a controlled 45 x 45 dispersion pattern to reduce unwanted reflections while still delivering room filling sound. With a common footprint, this is an excellent tweeter for use as a replacement.

| PRO Audio | High Frequency Driver + 44? Horn

Specs:
150 Watts Continuous Power
75 Watts RMS Power
Impedance: 8 Ohm
Sensitivity: 108 dB
Frequency Response: 1.3 KHz 19 KHz
1? Voice Coil
Phenolic Diaphragm
Ferrite Driver
Sizing:
Mounting Depth: 4.64? (117.8 mm)
Mounting Cutout size: 3.50? x 3.50? + Terminal
Overal size: 4.50? Wide x 4.50? Length x 4.92? Height
Weight: 1.15 Lbs

New Slim Design Available TPT-DH175 SLIM
