Description
xFeatures
The Titanium diaphragm is on a Kapton former is light, thin and durable for long play applications. The TW350Ti is perfect for DJ Cabinets, and can may be for higher SPL Requirements. The sharp smooth sound is perfect for applications where larger compression drivers may over power a venue.
TW350Ti is designed with cast aluminum frame to ensure a quality sound and long lasting play in most any environment. Replacement Diaphragms available.
Add crystal clear sparkle to any speaker with PRV Audios TW350Ti titanium bullet super tweeter! Not only does this driver look as good as it sounds and its also able to take a huge amount of power due to its 1? diameter copper voice coil.
The PRV Audio TW350Ti Super Tweeter offers a smooth response and extremely high efficiency from mid range through high range frequencies.
Highlights
- Type: Super Tweeter
- Nominal Impedance: 8?
- Rated AES Power Handling (RMS): 60 Watts
- Program Power: 120 Watts
- Voice Coil Diameter: 1?
- New SLIM version available at 4 ohms TW350Ti-4 SLIM
GENERAL SPECIFICATIONS
| Nominal impedance | 8 Ohms |
| Rated AES Power Handling (RMS) | 60 Watts |
| Program Power | 120 Watts |
| Sensitivity 2.83V at 1m | 105 dB |
|
Recommended Hi Pass Crossover** **For Full Power Handling |
5000 Hz** **12db Per Octave Crossover |
| Frequency Response at -10dB | 3,500 20,000 Hz |
| Voice Coil Diameter | 1(25 mm) |
| Voice Coil Wire | CCAW |
| Voice Coil Former Material | Kapton |
| Diaphragm Material | Titanium |
| Flux Density | 1.70 T |
| Magnet Material | Ferrite |
EXTRA INFO
| Overall Depth | 2.43 (68 mm) |
| Mounting Depth | 2.08 (53 mm) |
| Overall Width | 3.06 (77.7 mm) |
| Overall Height | 3.5 (89 mm) |
| Cutout Diameter | 2.75 (70 mm) |
| Net Weight | 1.37 lbs (0.62 kg) |
| Shipping Weight | 1.47 lbs (0.67 kg) |
| Carton Dimensions W x L x H | 3.86 x 3.42 x 2.75 (98 x 87 x 70 mm) |
PRV AUDIO TW350Ti DATASHEETDownload
