Memphis SE1200.4V2 4 Channel Street Edge Series Amplifier 85W x 4@2ohm

Memphis SE1200.4V2 4 Channel Street Edge Series Amplifier 85W x 4@2ohm

Product Details:

• Memphis Audio Street Edge Series Class D 2 ohms Stable 4-Channel-Channel Amplifier
• RMS Power Rating:
• 4 ohms: 60 watts x 4 channel
• 2 ohms: 85 watts x 4 channel
• Bridged, 4 ohms: 170 watts x 2 channel
• Total power output: 240 watts
• Pulse Width Modulated MOSFET power supply
• LED Power/Protect Light
• Speaker-level (high-level) inputs
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• Input sensitivity:
• Low level: 0.15mV - 16 volts
• High level:
• Frequency Response: 10 - 30000 Hz
• Total Harmonic Distortion (THD): 0.1%
• Signal to Noise Ratio: 85 dB
• Variable high-pass filter: 120 - 3000 Hz
• Variable low-pass filter: 50 - 250 Hz
• Variable Bass Boost: 0 - 12 dB
• Fuse Rating: 40A
• 8 AWG gauge power and ground wiring is recommended for installation.
• Dimensions: 8.07" W x 12.6" L x 2" H
