iDatalink HRN-HRR-TO2 + ADS-MRR
Connect a new car stereo and retain steering wheel controls and factory amp in select Toyota-made vehicles
Datalink working with Toyota
iDatalink's HRN-HRR-TO2 wiring adapter works in conjunction with iDatalink's Maestro ADS-MRR or ADS-MRR2 module, allowing you to connect a new car stereo in select 2012-19 Toyota-made vehicles, Once connected, you'll retain the use of your steering wheel audio controls and your factory amp in these vehicles.
The package includes connectors that plug in between the Maestro module and your factory radio's wiring plugs. You'll have to solder or splice together this harness's power/ground, illumination, speaker, and navigation output wires to the corresponding wires on your aftermarket receiver's wiring harness.
An iDatalink-ready car stereo takes full advantage of this harness
If you're buying a compatible iDatalink-ready car stereo, you'll enjoy the outstanding performance of your receiver, plus seamless touchscreen control over most of the factory features in select Toyota-built vehicles, including your backup camera and vehicle settings menu. You'll also appreciate the additional features added by the adapter, including the ability to view performance gauges and vehicle information on the screen with select iDatalink-ready receivers. This harness features an in-line head-unit connector harness, which will plug into their new "Head-unit direct" harnesses for select radio brands. If you're installing a radio that doesn't work with a "Head-unit direct" harness, you simply cut off the plug and connect the wires to the harness included with your new radio.
Product highlights:
allows installation of a new car stereo in select Toyota vehicles (also requires the Maestro ADS-MRR or ADS-MRR2 module)
retains the use of your steering wheel audio controls and factory amp with any car stereo
retains these factory features with an iDatalink-ready stereo:
fader
vehicle settings personalization menu
aux input
backup camera
displays performance data and gauges on touchscreen with select iDatalink-ready receivers
warranty: 1 year Manufacture
MFR # HRN-HRR-TO2
What's in the box:
iDatalink HRN-HRR-TO2 owner's manual
Vehicle/radio harness
Preout harness
OBDII harness
A harness
B harness
Compatible Vehicles
2012 Toyota Camry
2012 Toyota Camry Hybrid
2012 Toyota Prius
2012 Toyota Prius C
2012 Toyota Prius V
2013 Toyota Avalon
2013 Toyota Avalon Hybrid
2013 Toyota Camry
2013 Toyota Camry Hybrid
2013 Toyota Prius
2013 Toyota Prius C
2013 Toyota Prius V
2013 Toyota RAV4
2013 Toyota Venza
2014 Toyota 4Runner
2014 Toyota Avalon
2014 Toyota Avalon Hybrid
2014 Toyota Camry
2014 Toyota Camry Hybrid
2014 Toyota Corolla
2014 Toyota Highlander
2014 Toyota Highlander Hybrid
2014 Toyota Prius
2014 Toyota Prius C
2014 Toyota Prius V
2014 Toyota RAV4
2014 Toyota Sequoia
2014 Toyota Tacoma
2014 Toyota Tundra
2014 Toyota Venza
2015 Toyota 4Runner
2015 Toyota Avalon
2015 Toyota Avalon Hybrid
2015 Toyota Camry
2015 Toyota Camry Hybrid
2015 Toyota Corolla
2015 Toyota Highlander
2015 Toyota Highlander Hybrid
2015 Toyota Prius
2015 Toyota Prius C
2015 Toyota Prius V
2015 Toyota RAV4
2015 Toyota Sequoia
2015 Toyota Sienna
2015 Toyota Tacoma
2015 Toyota Tundra
2015 Toyota Venza
2016 Toyota 4Runner
2016 Toyota Avalon
2016 Toyota Avalon Hybrid
2016 Toyota Camry
2016 Toyota Camry Hybrid
2016 Toyota Corolla
2016 Toyota Highlander
2016 Toyota Highlander Hybrid
2016 Toyota Prius
2016 Toyota Prius C
2016 Toyota Prius V
2016 Toyota RAV4
2016 Toyota Sequoia
2016 Toyota Sienna
2016 Toyota Tacoma
2016 Toyota Tundra
2017 Toyota 4Runner
2017 Toyota 86
2017 Toyota Avalon
2017 Toyota Avalon Hybrid
2017 Toyota Camry
2017 Toyota Camry Hybrid
2017 Toyota Corolla
2017 Toyota Highlander
2017 Toyota Highlander Hybrid
2017 Toyota Prius
2017 Toyota Prius C
2017 Toyota Prius V
2017 Toyota RAV4
2017 Toyota Sequoia
2017 Toyota Sienna
2017 Toyota Tacoma
2017 Toyota Tundra
2018 Toyota 4Runner
2018 Toyota 86
2018 Toyota Avalon
2018 Toyota Avalon Hybrid
2018 Toyota C-HR
2018 Toyota Corolla
2018 Toyota Highlander
2018 Toyota Highlander Hybrid
2018 Toyota Prius
2018 Toyota Prius C
2018 Toyota RAV4
2018 Toyota Sequoia
2018 Toyota Tacoma
2018 Toyota Tundra
2019 Toyota 4Runner
2019 Toyota 86
2019 Toyota C-HR
2019 Toyota Corolla
2019 Toyota Highlander
2019 Toyota Highlander Hybrid
2019 Toyota Prius
2019 Toyota Prius C
2019 Toyota Sequoia
2019 Toyota Tacoma
2019 Toyota Tundra
2020 Toyota 86
2020 Toyota Tundra
2021 Toyota Tundra
iDatalink Maestro RR Interface Module
Connect a new stereo and retain the steering wheel audio controls and factory amps in select 2006-up vehicles
iDatalink's Maestro ADS-MRR module, along with the correct interface harness for your vehicle, allows you to install a new car stereo in select 2006-up Ford/Lincoln/Mercury, GM, Chrysler/Dodge/Jeep/RAM, Toyota/Scion, Honda/Acura, Fiat, Subaru, Volkswagen/Audi, and other vehicles while retaining your factory steering wheel audio controls and the use of your factory amplifier, if present.
Here's how it works
First, you connect the Maestro to your computer using the included USB cable, visit www.idatalink.com/maestro, and follow the instructions. Once the unit has been "flashed," it's ready to go. Next, you'll either solder or crimp the vehicle-specific Maestro harness (sold separately) to your new receiver's wiring, just like you would with any Crutchfield wiring harness or wiring adapter.
Important Note: You will also need an additional Maestro vehicle-specific wiring harness that connects your new receiver to the ADS-MRR module and your vehicle's wiring. We will automatically add this harness to your Cart at a discounted price when you purchase a new car stereo and this ADS-MRR module.
Retain steering wheel audio controls, too
The ADS-MRR module also allows you to use your factory steering wheel audio controls with your new receiver. Using the intuitive web programming interface, each factory button can be assigned a specific radio function. Better yet, you can also assign a secondary "press and hold" radio function to each factory button, effectively doubling what can be controlled.
Keeping your factory features with an iDatalink-ready car stereo
If you're buying a compatible Kenwood, JVC, Pioneer, Sony, or Alpine receiver, you'll enjoy the outstanding performance of your receiver, plus seamless touchscreen control over most of the factory features in select vehicles.
Chrysler: You'll retain the use of the Uconnect® system (including voice command), along with your steering wheel audio controls and factory amp.
Fiat: You'll retain your vehicle's factory amp, USB port, and backup camera.
Ford: You'll keep your SYNC® system, including the factory Bluetooth, satellite radio (in select vehicles, see Details), steering wheel audio controls, and other great features.
GM: You'll retain the use of OnStar® system, along with your steering wheel audio controls, your factory amp, and safety warning chimes.
Honda: You'll retain your vehicle's steering wheel controls, Bluetooth, aux input, and factory amplifier.
Subaru: You'll retain your steering wheel controls, factory amp and sub, and Subaru backup camera.
Toyota: You'll retain your vehicle's A/V input, USB port, and backup camera.
Product highlights:
allows installation of a new car stereo in select 2006-up Ford/Lincoln/Mercury, GM, Chrysler/Dodge/Jeep/RAM, Toyota/Scion, Honda/Acura, Fiat, Subaru, Volkswagen/Audi, and other vehicles
works with required vehicle-specific harness (sold separately) to retain factory steering wheel audio controls, retain the factory amp if present, and integrate all car stereo connections
retains factory convenience features (OnStar, SYNC, Uconnect, and more) with select Kenwood, Alpine, Pioneer, and JVC touchscreen receivers
displays engine performance data on touchscreen with select Kenwood, JVC, Pioneer, Sony, and Alpine multimedia receivers
dimensions: 4-1/8"W x 3/4"H x 2-7/8"D
What's in the box:
Radio replacement interface module
23" Wiring harness (18-pin to bare-wires)
23" Power/Ground harness (3-pin to bare-wires)
18" Interface harness (4-pin to 4-pin)
18" SWC harness (4-pin to 3.5mm/bare-wire)
22" Audio harness (3-Pin to 3.5mm)
3" Jumper harness (2-pin to 2-pin)
7" USB cable (microUSB to USB-A)
Quick Start Guide
