2 Pair of Alpine R2-S65 R-Series 6-1/2" + Pioneer GM-D8704 600W Class FD 4-Channel + 4 Gauge Amp Kit

2 Pair of Alpine R2-S65  R-Series 6-1/2" 2-way car speakers +

Pioneer GM-D8704 1200 W Max Power 4-Ch +Raptor R2AK4 4 Gauge Complete Amp Kit

Alpine R2-S65

Next-Generation R-Series 6-1/2" 2-way car speakers

Using technology developed for their flagship F#1 Status Series, Alpine built their Next-Generation R-Series Pro Series speakers to be accessible and fun for enthusiasts who are into high-resolution audio playback. Play your high-res music files with confidence, knowing that the ultra-wide frequency response of these speakers will provide the detailed, authentic sound you're looking for.

Minimal distortion

Alpine optimizes their R2-S65 6-1/2" 2-way speakers for near-perfect sound from premium sources. The combination of a highly rigid aluminum frame and a lightweight glass-fiber reinforced woofer cone keeps the sound clean. The high-amplitude multi-roll surround maximizes impact while maintaining linearity, so you'll get punch to go with the clarity. And speaking of a little more punch, Alpine ups the mid-bass output with a ferrite magnet and larger motor structure.

Loud and fun

All the exquisite detail you need is handled by a 1" magnesium hard dome tweeter, which contributes to the "loud and fun" sound associated with Alpine's R-Series. These speakers make a great addition to any high-powered system, thanks to power-handling up to 100 watts RMS. Hook ‘em up and play ‘em loud!

Product highlights:

6-1/2" 2-way car speakers (pair)

glass-fiber woofer cone with High-Amplitude Multi-Roll surround

1" magnesium hard dome tweeter

handles up to 100 watts RMS (300 watts peak power)

frequency response: 65-40,000 Hz

grilles included

warranty: 1 year

What's in the box:

Two 2-way Speakers

Two multi-purpose adapter rings (includes GM/Chrysler)

Two grilles

Eight 1-1/8" Screws

Eight M4x12mm Machine screws

8 Speed clips

Warranty information

Important Notice

On-line product registration information

Template and specs on box

Pioneer GM-D8704

600W Class FD 4-Channel GM Digital Series Amplifier w/ Wired Bass Boost Remote

Product highlights

• 100W x 4-Chan. @ 4 ohms

• 150W x 4-Chan. @ 2 ohms

• 125W x 4-Chan. @ 1 ohm

• 3-Way System Protection

• 4/3/2 Channel Operation

• 4 Gauge Power and Ground Inputs

• High Power Capability with Small Size

General Features:

GM Digital Series 4-Channel Class FD Car Amplifier w/ Wired Bass Boost Remote

RMS Power Rating:

4 ohms: 100 watts x 4 chan.

2 ohms: 150 watts x 4 chan.

1 ohm: 125 watts x 4 chan.

Bridged, 4 ohms: 300 watts x 2 chan.

Max power output: 600 watts x 2 chan.

Pulse Width Modulated MOSFET power supply

LED power (green) and protect (red) indicators

4/3/2 channel operation

Preamp RCA outputs to daisy chain multiple amps

3-way protection circuitry (thermal, overload, and speaker short protection)

High-density split-dome convection heat-sink for extreme heat dissipation

Nickel-plated RCA level inputs

Nickel-plated screw terminals

Input sensitivity:

Low level: 200mV-6.5V

High level: 0.8V-16V

Variable high-pass filter (40-500 Hz, 12 dB/octave)

Variable low-pass filter (40-500 Hz, 12 dB/octave)

CEA-2006 compliant amplifier

Frequency response: 40-50,000 Hz

4 gauge power and ground wiring is required for installation.

Dimensions: 10-7/16"W x 2-3/8"D x 7-7/8"H

Raptor R2AK4 4 Gauge Complete Amp Kit w/ RCA for Up to 1100W Systems

BULK SERIES 4 GAUGE AMP KIT

Complete Amp Kit

4 AWG Amp Kit with RCA

For up to 1100W Systems

CCA (Copper Clad Aluminum)

Includes (1) One 17ft Twist RCA Cable, (1) One 17ft 4 AWG CCA Power Cable, (1) One 3ft 4 AWG CCA Ground Cable, (1) One 17ft 18 AWG Turn-On Wire, (1) One 20ft Side-by-Side Speaker Wire, (1) One ANL Fuse Holder with 100 Amp Fuse, (4) Four Nickel Plated 4 AWG Seamed Ring Terminals, (5) Five Nickel Plated 16-14 Gauge Spade Terminals and Hardware
